Pulsar Axion XQ30 PRO Monocular 77506

Regular price
$1,499.97
Sale price
$1,499.97
Regular price
Shipping calculated at checkout.

Pulsar Axion XQ30 PRO Monocular

Axion XQ Pro thermal imaging monocular can be used for both day and night-time activities, even under challenging weather conditions (such as fog, smog, and rain) and in areas with obstacles like branches, tall grass, and dense shrubs. Unlike night-vision devices that rely on electron-optical converters, thermal vision monoculars do not need an external light source and are not affected by bright light. They are perfect for night-time hunting, observation, terrain orientation, and rescue operations.

Features

  • Highly sensitive thermal imaging sensor
  • Wide FOV for easy scanning
  • Compact pocket-sized design
  • Rugged magnesium alloy housing
  • Photo and video recording
  • Sensitivity amplification levels
  • A selection of 8 color palettes
  • Stream Vison 2 app support for iOS and Android
  • Frost-resistant AMOLED display
  • Long-life removable battery
  • Fast charting with USB Type-C
  • IPX7 Waterproof rated
  • Picture-in-picture Function

Specifications

Model

XQ30 Pro

SKU

PL77506

Microbolometer



Type

uncooled

Resolution, Pixels

384х288

Pixel Pitch, µm

17

NETD, mK

< 25

Frame Rate, Hz

50

Optical Characteristics



Optical Magnification, x

2

Smooth Digital Zoom

2-8

Digital Zoom, x

x1, x2, x4

Relative Aperture, D/f'

1.2

Minimum Observation Distance, m/y

3/3.28

Exit Pupil Diameter, mm

4

Angular Field of View (Horizontal x Vertical), degree

13.3x10

Linear Field of View (Horizontal x Vertical), m at 100 m

23.3x17.5

Eyepiece Focus Range, Diopter

+4 / -5

Detection Distance for Deer-Sized Objects, m/y

1050/1148

Display



Type

AMOLED

Resolution, Pixels

640x400

Operational Characteristics



Power Supply, V

3 - 4.2

Battery Type/Capacity/Nominal Output Voltage

APS 3 Li-ion Battery Pack / 3200 mAh / DC 3.7 V

External Power Supply

5 V (USB Type-C)

Battery Run Time at t=22°C, hours*

7.5

Degree of Protection, IP Code (IEC60529)

IPX7

Operating Temperature Range, °C / °F

-25 … +40 / -13 – +104

Dimensions, mm/inch

144x41x69 / 5.67x1.6x2.72

Weight (without battery), kg/oz

0.31/10.93

Video Recorder



Photo/Video Resolution, Pixels

528х400

Video/Photo Format

.mp4 / .jpg

Built-in Memory

16 GB

Frequency

2.4/5 GHz

Standard

IEEE 802.11 b/g/n/ac
