Final Few Sale AGM Rattler TS19 256 Thermal Scope

Final Few Sale AGM Rattler TS19 256 Thermal Scope

Regular price $895.00 USD
Regular price Sale price $895.00 USD
Sale Coming Soon
Shipping calculated at checkout.

FREE SHIPPING

The AGM Rattler TS19 256 was designed to be a compact thermal imaging scope that has 24 hour operation under any conditions. Two objective lens options allow the user to choose the perfect unit for short to medium range missions.

The Rattler features a 256×192, 12μm thermal detector and 1024×768 OLED monitor, which provides clear image under harsh environment conditions. It is powered with two CR123 batteries and gives up to 4.5 hours of continuous operation time. An externa 5V power bank (battery pack) can be easily connected via USB connector for a significant increase of operating time. Onboard WiFi module for live video streaming and video/images recording via application is also available.  The Rattler TS19-256 can be used as a thermal riflescope or handheld monocular, and can be used for patrolling, hunting and more.

AGM Rattler TS19 256 Features

256×192 thermal resolution, 12μm, high sensitivity detector

Image processing technology: Adaptive AGC, DDE, 3D DNR

1024×768 resolution 0.39 inch OLED display

8x digital zoom

Video recording and snapshot, built in EMMC (16 GB)

Supports distance measurement

Adjustable color palettes

WiFi data transmission

Waterproof, shockproof

Up to 4.5 hours continuous working

External power supply capability

Make him with a single OR A double latch QD mount

Limited 3 year warranty

******PLEASE NOTE*******
UNFORTUNATELY with the price point of this Scope—NO FREE GIFTS ARE included in this item! We appreciate you & your business! If you would like to order the Battery Pack & Cable to go along with this just add it to your order.  We do also have a set of extra CR123 Batteries you can also add to your cart for this item!

 Thank you for understanding!

Data Sheet




Specifications

Battery Life



(Operating at 20°С)

Up to 4.5 hr
Palettes Black Hot



White Hot

Red Hot

Fusion

Reticle 5 types, 3 colors, on/off
Drop Test Height 1.5m



(4.9 feet)

Boresight Adjustment Digital Controlled
Boresight Increment 0.22 mil / 0.77 MOA
Distance Measurement Yes (Stadiametric Rangefinder)
Scene Mode Jungle, Recognition
Picture In Picture Mode (PIP) Yes
Hotspot Yes
Video Recording Yes
Defective Pixels Correction (DPC) Yes
Uniformity Correction Auto, Manual, External Correction
Observation Distance Max. 950 m
Detector Type 12μm, Uncooled, 25 Hz
Standby Mode Yes
Resolution 256 × 192
Snapshot Yes
Lens System 19 mm; F/1.0
Optical Magnification 2.5× – 20×
Field of View (H × X) 9.24° × 6.94°
Digital Zoom 1×, 2×, 4×, 8×
Eye Relief 45 mm
Display 0.39 inch, OLED, 1024×768, 50 Hz
Storage Built in EMMC (16 GB)
Battery Type Two CR123 (3V) Lithium
CVBS Output Yes (via USB)
External Power Supply 5 VDC/2 A, USB Type-C interface
Operating Temperature Range -20°C to +55°C



(-4°F to +131°F)

Degree of Protection IP67
Weight 520 g



( 1.15 lb)

Overall Dimensions 187 × 63 × 80 mm



(7.4 × 2.5 × 3.1 in)

Package Includes Thermal Imaging Rifle Scope



Mount

USB Cable

Lens Cloth

Manual



View full details
